P. 109
LOCKING PLUG & CONNECTOR
Enchufe de Bloqueo Giratorio
INDUSTRIAL GRADE LOCKING PLUGS &
CONNECTORS 3P
˙ Material：Housing – Nylon；Belly – PBT
˙ 2-Pole, 3-Wire Grounding
˙ Back Wire Terminal Clamps For Easy Secure Wiring
˙ Body Size：47mm
Catalogue No.
Plug Connector
50154 50154F 15A 125V NEMA L5-15
50155 50155F 15A 250V NEMA L6-15
50156 50156F 15A 277V NEMA L7-15
50164 50164F 20A 125V NEMA L5-20
50165 50165F 20A 250V NEMA L6-20
50166 50166F 20A 277V NEMA L7-20
50167 50167F 20A 480V NEMA L8-20
50174 50174F 30A 125V NEMA L5-30
50175 50175F 30A 250V NEMA L6-30
INDUSTRIAL GRADE LOCKING PLUGS &
CONNECTORS 4P
˙ Material：Housing – Nylon；Belly – PBT
˙ 3-Pole, 4-Wire Grounding
˙ Back Wire Terminal Clamps For Easy Secure Wiring
˙ Body Size：54.6mm
Catalogue No.
Plug Connector
50184 50184F 20A 125/250V NEMA L14-20
50185 50185F 20A 250V NEMA L15-20
50186 50186F 20A 480V NEMA L16-20
50188 50188F 20A 120/208V NEMA L21-20
50189 50189F 20A 277/480V NEMA L22-20
50194 50194F 30A 125/250V NEMA L14-30
50195 50195F 30A 250V NEMA L15-30
50196 50196F 30A 480V NEMA L16-30
50197 50197F 30A 600V NEMA L17-30
50198 50198F 30A 120/208V NEMA L21-30
50199 50199F 30A 277/480V NEMA L22-30
107
