LOCKING FLANGED INLET 4P 20 / 30A

˙ Material：Polyamide or Polycarbonate
˙ 3-Pole, 4-Wire or 4-Pole, 5-Wire Grounding

FG50184 20A 125/250V NEMA L14-20P
FG50185 20A 250V NEMA L15-20P
FG50186 20A 480V NEMA L16-20P
FG50188 20A 120/208V NEMA L21-20P
FG50189 20A 277/480V NEMA L22-20P
FG50190 20A 347/600V NEMA L23-20P
FG50194 30A 125/250V NEMA L14-30P
FG50195 30A 250V NEMA L15-30P
FG50196 30A 480V NEMA L16-30P
FG50197 30A 600V NEMA L17-30P
FG50198 30A 120/208V NEMA L21-30P
FG50199 30A 277/480V NEMA L22-30P
FG50200 30A 347/600V NEMA L23-30P

LOCKING FLANGED OUTLET 4P 20 / 30A

˙ Material：Polyamide or Polycarbonate
˙ 3-Pole, 4-Wire or 4-Pole, 5-Wire Grounding

FG50184F 20A 125/250V NEMA L14-20R
FG50185F 20A 250V NEMA L15-20R
FG50186F 20A 480V NEMA L16-20R
FG50188F 20A 120/208V NEMA L21-20R
FG50189F 20A 277/480V NEMA L22-20R
FG50190F 20A 347/600V NEMA L23-20R
FG50194F 30A 125/250V NEMA L14-30R
FG50195F 30A 250V NEMA L15-30R
FG50196F 30A 480V NEMA L16-30R
FG50197F 30A 600V NEMA L17-30R
FG50198F 30A 120/208V NEMA L21-30R
FG50199F 30A 277/480V NEMA L22-30R
FG50200F 30A 347/600V NEMA L23-30R
